SYSTEM INFORMATION

Power Requirements: 110/220VAC (1 to 2.6kW)
Depth Rating: Up to 305m (1,000ft)
Submersible Weight in Air: 10kg (22lbs)
Total System Weight (sub and UCC): 34.8kg (76.9lbs)
Communications Protocol: RS-485 and Ethernet
Speed: >4.4 knots (forward)
Cases: 2-3 Watertight Rugged Hard Cases
Owner’s Manual: Online Digital
System Tool Kit: Included
Warranty: 2 Year Comprehensive

OPTIONS

Tether Data Transmission: Copper
Payload**: BluePrint Sonar (750D or 1200D), Single axis or dual axis manipulator, Micron USBL or SeaTrac USBL

**Note: Given the smaller size of the Pro 5, not all Mission Specialist payload options for the Defender configuration will be able to integrate with the Pro 5. If you have any specific questions about accessory integrations, please contact an account executive at sales@videoray.com or +1 (610) 458-3000 option 2.

SYSTEM INFORMATION

Power Requirements: 110/220VAC (1 to 2.6kW)
Depth Rating: Up to 1,000m (3,280ft)
Submersible Weight in Air: 17.2kg (38lbs)
Total System Weight (sub and UCC): 32.5kg (71.6lbs)
Communications Protocol: RS-485 and Ethernet
Speed: 4 knots (forward)
Bollard Pull: 23.5kg (52lbs)
Lift: 11.3kg (25lbs)
Cases: 2 Watertight Rugged Hard Cases
Owner’s Manual: Online Digital
System Tool Kit: Included
Warranty: 2 Year Comprehensive

OPTIONS

Tether Data Transmission: Copper or Fiber Optic depending on length required
Payload: Customizable depending on mission and requirements
